PRESSURE GAUGE, DIAPHRAGM, HEAVY DUTY PN25 , KLAUS FISCHER MS12

The MS12 processes the output signal of the integrated pressure sensor digitally. A versatile parameter driven micro controller actuates on the display and the switching outputs. Optionally it produces a new output signal. The signal can be slewrate limited, spreaded, inverted, and transformed nonlinearly by means of a table fuction. The parameters may be entered directly using the membrane sealed keypad or using a PC connected with a serial interface adaptor.s.

FEATURES

• Large bright LED display

• Selectable pressure units

• 2 independent limits with a choice of logic modes

• User-defined look-up table for signal conversion,
  with up to 30 points

AplicAtions

• Pressure switch / pressure display for unconvenient
  accessible measuring places

•  machine instrumentation

• Level measurement

• Simplified pump control
