APM, the Next Generation of Panel Meter



Política de entrega (editar con el módulo de Información de seguridad y confianza para el cliente)

APM, the Next Generation of Panel Meter





CHARACTERISTICS

  • 2 alarms set points
  • Analogic Output
  • Dynamic backlight colour
  • 40 segments bar graph display



Visiviluty

  • Large display
  • User adjustable backlight brightness and colour
  • Custom anunciators
  • Wide viweing angle
MEASUREMENT
Voltage
Current
Frequency
Input range (DC)
0 - 600V
0 -5A
-
Input range (AC)
0 -528V
0 -5A
0 - 400Hz
Display modes
1%
1%
0.1%
Display modes
Peak or RMS

ENVIRONMENT
Temperature - operating
-10 to +60°C

Temperature - storage
-40 to +70°C

IP rating (from the front)
IP65

POWER SUPPLY
Nominal Input (AC or DC)
12 - 24 VAC/VDC

DISPLAY
Number of digits
4

Digit height
12mm

Number of message characters
4

Backlight colors
Red, Green, White

LCD display
Positive or Negative

OUTPUT MODELS
Max voltage
24V

Max current
50mA

Analogue Output
4 - 20mA

CERTIFICATION
UL and cUL (Pending), CE
