Key Features: Differential Pressure Transmitter Indicator Fischer DE39

The Fischer DE39 is a multifunctional digital differential pressure transmitter with 4-digit LCD display and color change (green/yellow/red), engineered for accurate measurement and transmission of differential pressure, overpressure, and partial vacuum in neutral gaseous and liquid media. Covers ranges from **0…0.6 bar to 0…40 bar** (per model), with configurable analog output 4-20 mA or 0-10 V, 24 V DC/AC supply, and backlit display that changes color for instant visual alarm indication. Process connection via cutting ring fitting for 6-8 mm tubes, rugged housing with IP65/IP67 protection. Selectable operating modes (differential, 2-channel relative pressure, or absolute pressure) and simple programming. As distributor at Garmasl, we highlight its 2.5% accuracy, intuitive visual alarm, and industrial versatility, positioning it as one of the best solutions in the market for differential pressure monitoring and transmission with advanced local indication and zero maintenance.

Main Specifications: Differential Pressure Transmitter Indicator Fischer DE39

• Measuring range: 0…0.6 bar to 0…40 bar (per model)
• Pressure unit: bar, mbar, kPa, % (selectable)
• Analog output: 4-20 mA or 0-10 V
• Supply voltage: 24 V DC/AC
• Accuracy: 2.5 %
• Display: 4-digit LCD with color change and backlighting
• Process connection: Cutting ring fitting for 6-8 mm tubes

Applications and Benefits: Differential Pressure Transmitter Indicator Fischer DE39

Monitoring in HVAC and Filtration Systems: The DE39 measures differential pressure in filters, blowers, and compressors with instant color-changing display alarm for early clogging detection and airflow optimization, as an intuitive and efficient market solution for industrial climate control.

Benefits in Industrial and Pneumatic Processes: Transmits accurate analog signals to PLC/SCADA while providing real-time local value display, with ruggedness against pressure peaks and vibrations that minimizes failures and downtime in production lines.

Advantages in Heating and Heat Transfer Applications: High repeatability and color-changing display enable reliable differential pressure control in heating circuits and thermal systems, improving safety and operational efficiency without frequent calibrations.

Competitive Potential: 2.5% accuracy, 4-digit color display with visual alarm, configurable output, and German wear-free design make the DE39 excel in HVAC, manufacturing, air treatment, and pneumatic automation sectors, drawing inquiries for its ease of use, advanced local indication, and outstanding value in differential pressure transmitters with integrated display.
